System configuration and features
:
1.total
magnifying power : 200 times
2.Achromatic
objective lens : 4 times
magnification and 25mm effective
working distance
3.Coaxial
conjugate : range of rough
adjustment : 35mm range
of fine adjustment : 35mm
4.Coaxial
vertical and horizontal movement
of the platform : vertical
movement area 35mm ,
horizontal movement area 35mm .
5.electronic
light source :
rated voltage : 220V 50Hz mercury
lamp: 125W, tungsten lamp :250W,
fuse tube: 5A ,Power
of blower fan:18W
6.Fiber
bundle: diameter : 6mm ,
length : 1000mm ,
transmittance≥70%.
